Sealed ANSI Design Centrifugal Pumps Molded from Solid Kynar®

Designed specially for dirty, abrasive and corrosive process fluids

Stan-Cor Series pumps provide exclusive design advantages over all other centrifugal pumps.

For applications requiring durability and performance on dirty, difficult fluids, Stan-Cor pumps are by far the most cost-effective solution.

For applications requiring durability and performance on dirty, difficult fluids, Stan-Cor pumps are the most cost-effective solution.

  • SOLID KYNAR

    Solid Kynar designed for handling abrasive, dirty process fluids.
  • DYNAMIC HEAD

    Total dynamic head to 350 feet
  • FLOW RATES

    Flow rates to 700 gpm

Stan-Cor Patented Concentric Casing Advantages

How do Stan-Cor Centrifugal Pumps Work?

Unlike volute-type centrifugal pumps, the Stan-Cor pump uses a unique concentric design that provides a constant, equal distance between the pump casing and the impeller at all times during pump operation. This greatly reduces turbulence and vibration, thereby extending the life of the mechanical seal and bearings.

In a conventional volute casing pump, water turbulence and eddies are created as the impeller passes the restrictive cut water area in the casing. These hydraulic imbalances in turn cause the drive shaft to deflect, which increases the loading on the bearings, and leads to premature mechanical seal failure. At near shut-off, the bearing loading is extremely high.

The Stan-Cor concentric casing design eliminates these excessive hydraulic imbalances.

  • It allows the pump to run anywhere between a few gallons per minute and full ow without undue shaft deflection.
  • Moreover, the design allows the Stan-Cor pump to handle abrasives much better than standard models.

The sharp, restrictive cut water area of most pumps is the focal point for corrosion and erosion. It is the place where abrasives first attack a pump. With lined pumps, the thin liner is easily abraded away and the metallic backing exposed to the corrosive and abrasive forces of the product being pumped.

The Stan-Cor concentric casing design, coupled with its solid homogenous non-metallic component, eliminates this problem area.

Afterfifty years

of designing, assembling, testing and continuously improving Stan-Cor pumps, we are confident that we are producing great products in a timely,
cost-efficient manner at our high volume,
state of the art 113,000 sq.ft. manufacturing
facility located in Minneapolis, Minnesota.

SIMPLICITY

Precise, quality manufacturing. Stringent quality control systems for component-to-component and unit-to-unit quality and consistency.

RELIABILITY

100% Tested: 15 min. to 2 hour run cycle on every pump. We test every unit before shipping for full flow at rated pressure, temperature, noise, vibration, etc.

FLEXIBILITY

On-going cooperative product development with our customers ranging from simple product modifications to completely customized pumping systems.

REQUEST A QUOTE

Let us help you determine the best pump solution for your application.
